AC10B-60B, Modular Type, Air Filter/Regulator

AC10B-60B, Modular Type, Air Filter/Regulator Show Description

Convenient assembly of filter and regulator when lubricated air is not required.  The current AC series is no longer being produced and is subject to available quantities only.  For size 10 models, please utilize the AC-A series.  For sizes 50~60, please utilize the AC-B series.  For sizes 20~40, please utilize the AC-A or AC-B series as appropriate to your performance and option needs.

  • Air filter and regulator unit
  • Clean looking, modular design
  • Improved installation
  • Compact spacer with bracket reduces total assembly space
  • Optional embedded pressure gauge
  • Rc(PT), G(PF) or NPT threads
