SMC Products at Pack Expo Las Vegas - Booth LS-6169
SMC Corporation of America will exhibit at Pack Expo 2019 in Las Vegas. SMC will feature its wireless communication technology in EtherNet/IP™ protocol supporting solenoid valve manifolds, the innovation of a square piston actuator to optimize output to area ratio, a higher efficiency air booster/regulator and the latest technologies supporting Internet of Things in the industrial space.
SMC is a proud helping sponsor of the Packaging & Processing Women's Leadership Network (PPWLN) event
2 Port Dust Collector, Pulse Valve
The new JSXFA series is a high performance pulse valve for reverse jet dust collector applications. The JSXFA has variable port sizes and available in threaded and compression fitting connections. The JSXFA also has reduced air consumption and increased peak pressure. The heavy elastomer diaphragm allows the JSXFA to achieve its 10 million cycle life.
2 Port Direct Solenoid Valve
The VX2 series is 2 port direct solenoid valve for general purpose air, medium vacuum and water. Available body materials include resin, aluminum, brass or stainless steel with port size up to 1/2 inch. Resin body is offered with one touch fitting to reduce installation time. It is also available as a manifold to reduce piping.
4 and 5 Port Solenoid Valves
SMC has improved product performance and reliability with the redesigned SY series valve. The SY3000 and SY5000 have the same valve width as their predecessors, but the flow has been increased by up to 80%, allowing the valve size to be reduced. A built-in strainer in the pilot valve prevents trouble caused by foreign matter. By using H-NBR seal material for the main valve and seals, Ozone resistance has been improved. Side, top and bottom port/pipe directions are available to allow flexible installation. The SY is available in body ported or base mounted styles, and can be used individually or manifold mounted.
CG5 Stainless Steel Cylinders
The CG5-S series is a stainless steel cylinder that uses grease for food processing machines that meets FDA standards. The CG5-S series can be disassembled for replacement of seals which extends the service life of the cylinder. All stainless steel specification for external parts. Mounting bracket surfaces have been electropolished, making them smoother to prevent build-up of liquids and foreign matter. Plugs are provided for unused mounting threads to prevent residue build-up in the threads.
CJ5 Stainless Steel Cylinders
Series CJ5-S is a small bore stainless steel cylinder, designed for use in environments with water spray (such as food processing machines). A special scraper (standard) prevents water from entering the cylinder. Non-toxic additives allow confident use in equipment for food, beverage and medical products, etc. The CJ5-S series can be disassembled for replacement of seals.
NCM All Stainless Steel Cylinders
MGP Guided Actuators
Series MGP is designed for high side load applications found in material handling, lifting and stopping. The cylinder utilizes an ultra-compact design by incorporating the cylinder body as part of the guide body. As the stroke length increases, so does the bearing length, thus enhancing the cylinder's load bearing capacity. Order made options for this series include adjustable air cushions, heavy duty guide rods, copper free, high temperature, and low speed.
CXS Dual Piston Rods Actuators
The CXS Series is a dual piston actuator with non-rotating accuracy ± 0.1°. The CXSL high precision ball bushing type allows for smooth operation that ensures stable travel resistance. The CXSM slide bearing type provides lateral stability protecting it from side load impacts.
Fittings and Flow Control Equipment
KQB2 Metal One-Touch Fittings
KQG2 Stainless Steel One Touch Fittings
Series KQG2 is a one-touch fitting made of all stainless steel SUS316, except seal parts. The series is suitable for use with steam and is grease-free. Applicable tubing includes FEP, PFA, nylon, soft nylon, polyurethane and polyolefin. The KQG2 series is available in both metric and inch sizes. The KQG2 is more compact and lightweight, and offers more configuration variations and tube sizes than the KQG series.
ASG Stainless Steel Speed Controller
Suitable for applications where copper free specifications are required, the “–FG” series can also be used in areas where wash down could degrade standard flow controls, such as food and packaging. This series is designed to offer the maximum control by increasing the number of turns of the needle to 10. The body and adjustment are made of high impact white resin for a clean look. This series also incorporates SMC’s one-touch fitting available for tubing sizes from 4mm to 12mm OD.
EX600 Wireless SI Unit
The EX600 serial interface offers a full suite of diagnostics and programmable parameters to meet the most stringent requirements. The EX600 offers excellent flexibility including digital input, digital output and analog input unit options. With the use of D-sub output blocks, a maximum of 9 remote D-sub manifolds can be attached to one EX600 communication module. This serial interface is compatible with series SV1000/2000/3000, VQC1000/2000/4000, S0700 and the new SY series valves. Available protocols include Ethernet/IP™, PROFINET. The EX600 wireless cannot be used in countries where wireless is not supported. Refer to the catalog for details of countries where wireless is supported.
EX600 Fieldbus I/O System
The EX600 serial interface offers a full suite of diagnostics and programmable parameters to meet the most stringent requirements. The EX600 offers excellent flexibility including digital input, digital output and analog input unit options. With the use of D-sub output blocks, a maximum of 9 remote D-sub manifolds can be attached to one EX600 communication module. This serial interface is compatible with series SV1000/2000/3000, VQC1000/2000/4000, S0700 and the new SY series valves. Available protocols include PROFIBUS-DP®, DeviceNet™, CC-Link, Ethernet I/P™ and EtherCAT®, PROFINET, POWELINK and CC-Link IE Field™
AMG150C-550C/AMG650-850 Water Separator
The AMG series water separator is installed on the air pressure line to remove water drops from compressed air. It is available in 7 sizes with a variety of optional combinations to meet your application requirements.
IDFB Refrigerated Air Dryers
IDFB series refrigerated air dryers are cUL listed for use in North America. These 60 Hz models have rated flows up to 459 SCFM (780 m³/hr [ANR]).
IZS Bar Ionizers
By neutralizing static electricity, our IZS bar style Ionizer prevents damage to work pieces caused by sticking. Static charge removal time can be reduced with an optional sensor that directly senses charge allowing the removal of static electricity at high speed (0.3s) by generating the appropriate ion polarity. Needle cartridges can be replaced quickly to reduce down time. The IZS bar style Ionizer is available in various lengths to meet the specific needs of your work area.
IZT Bar Ionizer, Separate Controller and Power Supply Module
The IZT bar ionizer is an industrial static control solution. Bar ionizers generate a curtain of static eliminating ions effective for a distance up to 2000mm/6.5 ft. The IZT's low profile is also ideal for tight clearance installations. Compared to SMC's IZS4 bar ionizers, the power supply and control modules have been separated from the bar, resulting in a reduction in bar height. IZT bars can be placed closer to static-carriying materials in more confined adjacent spaces. The separate controller can be mounted in a workstation for easier access and observation during operation. Models include the standard IZT40, the IZT41 which adds auto-balance, emitter maintenance detection, and I/O signals, and the IZT42 with low amplitude ion generation for sensitive electronics. Extending the value of IZT, one controller can manage a maximum of 4 ionizing bars. Needle cartridges are easily removed, without tools, for cleaning or end-of-life replacement, futher extending this ionizer's value.
IZN Nozzle Ionizers
The IZN nozzle Ionizer provides a more compact anti-static solution. A 16mm body width permits installation in narrow spaces. This ionizer is perfect for the removal of static electricity on light electrical pieces and ideal for dust removal on injection molded parts.
IZF Fan Ionizers
Unlike bar or nozzle types, this fan ionizer does not require a pneumatic air supply. The fan draws in ambient air, then ionizes the air with four electrodes located around the perimeter of the discharge grill. The fan can be wired into a 24VDC machine power supply, or use the optional 120V AC adapter. The small form factor adapts well to enclosure mounting, or select the benchtop mounting bracket for free positioning.
Anti-Static Fittings and Tubing
Antistatic fitting and tubing is made from a conductive resin is making them ideal for high static environments.
Anti-Static Vacuum Cups
Anti-static suction cups are available in conductive NBR or anti-static urethane. The urethane pad surface resistance 109 to 1011Ω. Anti-static vacuum pad attachment is made from a conductive PEEK material
ZK2 Vacuum Generator
The ZK2 series is an energy-saving generator with 90% reduced air consumption. It has a 50% increase in suction flow compared to other single stage SMC generators. With its compact size and light weight, it is easier to maintain. The ZK2 also has various mounting options to choose from.
ZP3P Vacuum Cup Unit Without Adapter
The ZP3P series is made of a silicone rubber that is compliant with FDA21CFRSS1772600. The blue colored pad can be easily distinguished during contamination inspections. The sealing skirt design reduces leakage and offers a better sealing performance for film. Also incorporated into the design is a stopper support in the center to help wrinkle prevention on thin work pieces during adsorption.
ZP3P Vacuum Cup Unit With Adapter
The ZP3P series suction cups are made of a silicone rubber that is compliant with FDA21CFRSS1772600. The blue colored pad can be easily distinguished during contamination inspections. The sealing skirt design reduces leakage and offers a better sealing performance for film. Also incorporated into the design is a stopper support in the center to help wrinkle prevention on thin work pieces during adsorption.
Electric Actuator Controls and Drivers
Controllers and drivers needed for our electric actuator family. You will find step motor, servo motor and card motor controllers as well as 24VDC Fieldbus gateway units and AC servo drivers.
Electric actuators offer distinct advantages over their pneumatic counterparts. Acceleration and speed are controlled and predictable. Multiple positions are possible with high precision and repeatability. Pushing forces can be programmed. With no need for compressed air, infrastructure and energy costs are lower. LE is SMC's current line of electric actuators, designed with a focus on easy setup and operation. Function parameters come preset, plus an "Easy Mode" setting option allows you to be operational quickly. The LE line is available in a variety of types including: sliders, rod and guided rod, slide tables, rotary, grippers, and miniature. Accessories include actuator controllers, and gateways.
SMC's line of chillers and heat exchangers utilizes best-in-class technologies to accomplish the exact temperature ranges and stability desired by our customers. Our chillers and thermo-control units have proven performance in a wide range of applications.
IO-Link is a worldwide standardized I/O protocol, independent of any fieldbus or manufacturer. Communication is point-to-point and bidirectional, using a serial digital signal. ITV-X395 pairs IO-Link with an ITV electro-pneumatic regulator for digital control of the desired set pressure. The ITV-X395 connects to any IO-Link master with a single 4-wire, unshielded cable with an M12 connector. Send and receive pressure control signals, device information, and the setting parameters. Set pressure value has 12-bit resolution. An additional bit will indicate when set pressure is reached. Multiple parameters can be set to optimize performance. Parameters include initialization, gain and sensitivity tuning, zero an span adjustment, and hold/clear in response to an error. The front panel includes a power LED to indicate when power is supplied or there is an internal diagnosis error. A communication LED indicates stand-by or communication exchange, as well as a disconnect. Error codes for 3 conditions are also available.
Digital Pressure Sensor with IO Link
This next generation ISE70 pressure sensor provides continuous quantitative values, as well as switched digital outputs when pressure set points are met. This sensor is also IO-Link compatible. Sensor information, such as identity, functional state, cable connection, and current or switch values can be set or monitored remotely though an IO-Link master, and connected to a fieldbus network. The ISE70 is designed for abusive environments that may also include splashed coolant, lubricants or grime. Electronics are packaged in a metal housing, while the piping connection is a stout lug with female threads, which together protect the sensor against accidental collisions with other objects in the area. A smooth display face with membrane type buttons avoids contamination from grit and sticky residue that could clog or jam raised rubber buttons. The display is angled and can rotate 336 degrees, to permit easy reading when indirectly mounted. The main screen shows instantaneous values in red or green, while the sub screen setting appear in orange. Switch indicators will also light when set points are reached.
