Select values from the drop down lists or make appropriate selections to configure the part number.
Magnet
-- Pick an Option --
No Built-In Magnet
G (Built-In Standard Magnet)
P (Built-In Strong Magnet)
Clevis Width
-- Pick an Option --
A (12mm, ø32; 16.5mm, ø40, 50, 63)
B (19.5mm, ø50, ø63)
C (12.5mm, ø40, ø50, ø63)
Bore Size
-- Pick an Option --
32mm
40mm
50mm
63mm
Port Type
-- Pick an Option --
Rc1/4
TN (NPT1/4)
TF (G1/4)
Stroke
-- Pick an Option --
50mm
75mm
100mm
125mm
150mm
End Bracket
-- Pick an Option --
None
I (Single Knuckle Joint, M6 w/o Tap)
IA (Single Knuckle Joint, M6 w/Tap)
Y (Double Knuckle Joint, M6 w/o Tap)
YA (Double Knuckle Joint, M6 w/Tap)
Option
-- Pick an Option --
None
B (Limit Switch Mounting Base)
D (Dog Fitting)
L (Foot)
K (Pedestal, 75, 100, 150mm Strokes Only)
Locking Direction
-- Pick an Option --
B (Retraction Locking)
F (Extension Locking)
Port Piping Position
-- Pick an Option --
Port on Top, By-pass Piping on Left
2 (Port on Left, By-pass Piping on Right)
3 (Port on Right, By-pass Piping on Left)
4 (Port on Top, By-pass Piping on Right)
5 (Port on Left, By-pass Piping on Top)
6 (Port on Right, By-pass Piping on Top)
Switch Mounting Rod Position
-- Pick an Option --
Top (None If CLK2 Is Selected)
L (Left)
R (Right)
Auto Switch
-- Pick an Option --
No Switch, No Mounting Rod
M9B--Solid State, Gen. Purpose, 2 Wire, Horizontal
M9BA--Solid State, Water Resist., 2 Wire, Horizontal
M9BW--Solid State, 2-color Indication, 2 Wire, Horizontal
M9N--Solid State, Gen. Purpose, 3 Wire NPN, Horizontal
M9NA--Solid State, Water Resist., 3 Wire NPN, Horizontal
M9NW--Solid State, 2-color Indication, 3 Wire NPN, Horizontal
M9P--Solid State, Gen. Purpose, 3 Wire PNP, Horizontal
M9PA--Solid State, Water Resist., 3 Wire PNP, Horizontal
M9PW--Solid State, 2-color Indication, 3 Wire PNP, Horizontal
A90--Reed, AC Volt, Horizontal
A93--Reed, DC Volt, AC Volt, LED, Horizontal
A96--Reed, DC Volt, LED, Horizontal
P (No Switch, With Mounting Rod)
D-P3DWA--Solid State, 2-Color Indication, Magnetic Field Resistant, 2-Wire
D-P3DWAL--Solid State, 2-Color Indication, Magnetic Field Resistant, 2-Wire
D-P3DWASC--Solid State, 2-Color Indication, Magnetic Field Resistant, 2-Wire
D-P3DWASE--Solid State, 2-Color Indication, Magnetic Field Resistant, 2-Wire
D-P3DWAZ--Solid State, 2-Color Indication, Magnetic Field Resistant, 2-Wire
D-P4DWSC--Solid State, 2-Color Indication, Magnetic Field Resistant, 2-Wire
D-P4DWSE--Solid State, 2-Color Indication, Magnetic Field Resistant, 2-Wire
D-P4DWL--Solid State, 2-Color Indication, Magnetic Field Resistant, 2-Wire
D-P4DWZ--Solid State, 2-Color Indication, Magnetic Field Resistant, 2-Wire
D-P79WSE--Reed, Strong-Magnet Compatible, 2-Color Indicator, 2-Wire
D-P74--Reed, Strong-Magnet Compatible, 2-Wire
D-P74LS--Reed, Strong-Magnet Compatible, 2-Wire, L-Shape Connector
Lead Wire or Prewired Connector
-- Pick an Option --
0.5m (Or None in the Case of No Switch)
L (3m)
M (1m)
Z (5m)
SAPC (0.5m Cord Length, M8-3 Pin Connector)
SBPC (0.5m Cord Length, M8-4 Pin Connector)
SDPC (0.5m Cord Length, M12-4 Pin Connector)
MAPC (1.0m Cord Length, M8-3 Pin Connector)
MBPC (1.0m Cord Length, M8-4 Pin Connector)
MDPC (1.0m Cord Length, M12-4 Pin Connector)
SC (0.3m Cord Length, M12-4 Pin Connector, 3 & 4 Out)
Number
-- Pick an Option --
2 pcs. (Or None in the Case of No Switch)
S (1 pc.)
Auto Switch Mounting Type
-- Pick an Option --
Band Mounting (None If CLK2 Is Selected)
P (Rod Mounting)
Options in: Gray are not compatible with other selected option value.Red conflict with another selected option value.Amber are not recommended.
