LESYH, Electric Slide Table, High Precision Type, Battery-less

The LESYH is a high precision variation of the LESH high rigidity slide table.  This actuator improves positioning repeatability to ± 0.01 and increases vertical work load dramatically compard to the LESH.  The external motor can be mounted inline with the table, or in parallel to the left or right.  This version includes a 24VDC step motor with a battery-less absolute encoder.  This encoder allows the actuator to be powered down without losing its positional awareness.  The machine's PLC can access the controller's operational and positional step data through several fieldbus protocols, IO-Link, or parallel I/O.

  • Body size: 8, 16, 25
  • Strokes: 50, 75, 100 or 150mm
  • Maximum work load: 12 kg (horizontal, 20 kg (vertical))
  • Maximum pushing force: 420 N
  • Maximum speed: 400 mm/s
  • Positioning repeatability: ±0.01mm
LESYH, Electric Slide Table, High Precision Type, Battery-less
Configuration Options


Copy Configuration Number

Product Options

Select Product Options
Select values from the drop down lists or make appropriate selections to configure the part number.
Size Configuration Status
Motor Mounting Position Configuration Status
Lead Configuration Status
Stroke Configuration Status
Motor Option Configuration Status
Actuator Cable Type, Length Configuration Status
Controller Configuration Status
Mounting Configuration Status
I/O Cable Configuration Status
Communication Plug Connector Configuration Status
Options in:
  • Gray are not compatible with other selected option value.
  • Red conflict with another selected option value.
  • Amber are not recommended.
